UMAX One Utility Car
UMAX_One_ActionUMAX One Color Options

UMAX ONE Gas EFI

Standard 2-year limited vehicle warranty.

Available at all locations…ask us for more details!

Category:

Product Description

With six color options, luxurious bucket seats, under hood storage compartment, and large 20″ tires, you can see the difference when power, performance, versatility, and comfort matter.

  • Fuel System: Electronic Fuel Injection
  • ENGINE TYPE: Yamaha Built 402cc, Low Emission Single Cylinder 60deg Incline OHV
  • LUBRICATION SYSTEM: Splash-style positive oil lubrication
  • OIL CAPACITY: 1.16 U.S. quart (1.1 liter, 1100cc), Yamalube 10W-30 liter
  • COOLING SYSTEM: Forced air
  • STARTING SYSTEM: Starter generator with pedal start system
  • DIMENSIONS:
    Overall Length—111.45 in (283.1 cm)
    Overall Width—49.33 in (125.3 cm)
    Overall Height (with suntop)—71.81 in (182.4 cm)
    Overall Height (without suntop)—48.54 in (123.3 cm)
    Wheelbase—66.18 in (168.1 cm)
    Front Wheel Tread—39.96 in (101.5 cm)
    Rear Wheel Tread—40.19 in (102.1 cm)
    Minimum Ground Clearance—4.56 in (11.6 cm)
  • PERFORMANCE:
    Maximum Forward Speed—19.5 mph (31.4 km/h)
    Maximum Reverse Speed—17.5 mph (28 km/h)
    Minimum Turning Radius—3.48 m
    CHASSIS:
    FRAME: HybriCore™ chassis features a robotic welded automotive ladder-style steel frame protected with a multi-step full-immersion phosphate treatment, electro-deposition epoxy-based coating, and an electrostatic applied polyester/urethane powder topcoat
    BODY: Custom-formulated thermoplastic olefin painted with a two-part top coat of high-luster automotive-grade polyurethane
    STEERING: Self-compensating double reduction helical rack-and-pinion
    FRONT WHEEL SUSPENSION: Tru-Trak II™ fully independent automotive-style strut suspension
    REAR WHEEL SUSPENSION: Unit swing arm with DUAL RATE coil springs over hydraulic shock absorbers
    BRAKES: Self-adjusting mechanical, rear wheel drum brakes

Additional Information

Model

Yamaha

Make

UMAX One

Year

2018

Color

Available in Carbon, Evergreen, Noble Orange, Jasper, Aqua Blue, Glacier

Location

IA, IL, WI, NE
